Baldwin International has developed Tuffbraze 600 for industrial applications requiring the highest levels of strength and fatigue resistance. Tuffbraze 600 features a surface hardness of 600BHN (nominal – typical range is 565-625BHN) over a 500 BHN base (typical range is 465-515BHN). An ideal replacement for overlay, this wear plate provides the ultimate in penetration resistance, especially in applications where surfaces are being deteriorated by hard, sharp objects.
- Does not exhibit brittleness often associated with high-hardness alloys
- Work-hardens in service due to rich chemistry alloy
- Special chemistry alloy steel throughout:
- Does not have the weak mild steel base of overlay
- Clean, consistent grain structure
- More economical than overlay or ceramics
Benefits of Tuffbraze 600
- Exceptional in high-impact industrial applications requiring surface hardness.
- Outlasts even the best abrasion-resistant steels in the market, decreasing maintenance costs, while providing an economical substitute for overlay and ceramic type materials in many applications.
- American-made.
- Custom chemistry and machining processes yield the highest levels of hardness without the brittleness found in heat-treated generic wear plates.
- Ideal in a variety of applications, including: bucket liners, chutes, cones, liner plates, hoppers, impact plates, shot and sand blast equipment, target plates, truck body liners, etc.
- Tuffbraze 600 is available in various stock sizes and can be machined-to-order per your specifications.
Typical Mechanical Properties
| Tensile | 270,000 psi |
| Yield | 240,000 psi |
| % of elongation | 14% |
| Reduction in area | 35% |
| BHN hardness | 600 BHN |
Tuffbraze 600 Applications
Bucket Heel Plates
Bucket Lips
Chipper Components
Chutes
Cones
Conveyor Components
Crushing Mill Liner Plates
Cyclone Components
Drag Line Bucket Liners
Fan Blades
Fan Housing Components
Farm Machinery & Components
Flat Back Elbows
Grizzly Bars
Hoppers
Impact Plates
Impellers
Pug Mill Paddles
Railroad Maintenance Equipment
Screen Plates
Screw Conveyor Flights
Shot and Sand Blast Equipment
T-Injectors
Target Plates
Transitions
Truck Body liners
Wheelabrator Parts
Stock Range Size
| Thick. | 4×4 ft | 4×8 ft | 4×12 ft | 4×24 ft | 6×8 ft | 6×12 ft | 6×24 ft | 8×12 ft | 8×24 ft |
|---|---|---|---|---|---|---|---|---|---|
| 3/16 | X | X | X | X | X | X | X | ||
| 1/4 | X | X | X | X | X | X | X | X | X |
| 3/8 | X | X | X | X | X | X | X | X | X |
| 1/2 | X | X | X | X | X | X | X | X | X |
| 5/8 | X | X | X | X | X | X | X | X | X |
| 3/4 | X | X | X | X | X | X | X | X | X |
| 7/8 | X | X | X | X | X | X | X | X | X |
| 1 | X | X | X | X | X | X | X | X | X |
| 1 1/4 | X | X | X | X | X | X | |||
| 1 1/2 | X | X | X | X | X | X | |||
| 2 | X | X | X | X | X | X | X | X | X |
